Cracked block

I just cracked a block, back of number 2 cylinder.  Not happy. About 400hp at crank, 22psi, stock head and manual NA cams.  0.20th (0.5mm) oversized forged pistons. 7500rpm limit.
Its a Gen 3 NA block (its in a RWD corolla, and all 3SGTE blocks are shaved to suit GT4 so not goood for RWD).
Sounds like it happens a lot with gen 3 blocks.
I have another gen 3 NA block that has teh reinforced No1 cylinder (behind water pump), didnt know that was available in gen 3.
I also have a FWD beams motor (grey top) with reinforced block.
I just bought a 1995 5SFE block and a 1998 x20 series camry block.  I will post pics of all the blocks soon.
The x20 block does look to have thicker cylinder walls if you look in the water gallery).


Blacktop beams is not an easy conversion.  Need custom engine mounts, modify the intake manifold (brake booster in the way), Modify fuel rail for return line, and you get a sump that hits your sway bar.  Then there is the height issue and ECU issues, and it cant handle boost.  Also you have to use a Y bellhousing with it because the starter is on the drivers side

By using a NA block, I bolt on ST141 mounts, 5SFE oil and water pump, Spacia pickup, splash plate and sump, and weld up an intake manifold and water pipes and weld ST141 mounts to the crossmember (easy). I have a bunch of SA63 bellhousings and have done this conversion 3 times.  I also run Manual NA cams because they have much more duration then turbo cams.  The GT3071r is plenty big enough for a <250' cam motor (0.64 rear).  I found when I tried 268 cams the 0.86 rear was essential.  I run ~21psi daily, and the occational push to 25psi (maybe 28 by accident).  I had to run BRK8EIX to stop ignition problems above 22psi.

I am on my 5th gen 3 engine with this car tho :( but I do give it a hard time.
1. Forged, 40th Low Comp Arias pistons, spool rods.  Spun a big end after a month, and was running it NA! (Wrong pickup).
2. Same engine rebuilt with new crank - After a few months something sucked into the engine and scratched the bores and pistons.
3. Dead stock Caldina internals in a stock Gen 3 NA block - Got over a year out of it at ~22psi.  Took it to 25psi and broke a ring land.
4. SPS 20th pistons, spool rods - Cracked the cylinder at Willowbank after about 5 runs on my second week of racing. Still drove home.
5. SRP 86mm pistons, Late gen 3 reinforced block.  In car next week.

Good to hear that IDB is still around!  I bought 2TG valves and gears from you in the early 90s :)



I have a black top with a loom and ECU, but it is easier to fit a gen3 then it is to fit a black top (Mounts, intake manifold, sump issues and height to name a few).

OK I just examined 4 blocks, and it seams that not all reinfoced 5SFE blocks have the same cylinder wall thickness.
Gen 3 block - 7mm minus aprox 1.5mm (it recesses about 10mm down).
Noah (Spacia) 3SFE block - 7.5mm minus aprox 1.5mm (it recesses about 10mm down). NOTE has oil squirter blocks
1996 Celica 5SFE - 7mm with slight recess 12mm down.  No oil squirter blocks, no balance shafts (Same crank as camry 5S but no gear pressed on).
1998 Camry x20 5SFE - 8mm with slight recess 15mm down.  No oil squirter blocks.  Oil feed for balance shafts.

All of these blocks cept Gen 3 has the external reinforcement near water pump.
That crack of mine starts at the recess area :(

No spare cams.  All NA Gen3 have 250' intake.  Manuals have 250' exhaust as well.  I am running 2 intake cams.  Motors are from Caldina and MR2


ok too many pics for here so I put them on tumblr

I have a Gen 3 caldina GT-T head and 2 x Caldina NA Gen3 heads and a MR2 Gen 3 head.  All have -88362 exhaust, and all NA heads I have use -88460 intake.  The grey top exhaust has huge lift but much bigger base circle so shims would have to be reduced a lot! Also no dissy drive on a beams cam.


And whats with people saying beams rods are shorter - I think not!!


the beams rods is not shorted they're the same as caldina rods weaker than 3rd gen(same length as all 3s rods), they just have a lower comp height/crown height on the pistons, they run 1mm below deck height

Actually 6 engines (1 x Gen3 turbo (caldina), 4 x gen3 Auto NA (some MR2, some Caldina), 1 x grey top (caldina) and 1 x black top)  Then there is the 1 x 1996 celica manual 5S, 1 x 1998 camry auto 5S, 1 x 1998 Noah auto 3SFE but I threw those heads out lol
