SW20 315mm front/323mm rear upgrade
As many people know i had brackets made up years ago to make this conversion for various people. Since then i have had alot more interest in making them once again.
I have had another run of these made and have also obtained the bits that were missing from when i first made them (much higher quality/ADR approved lines etc) I can also supply TRW race pads to suit.
If anyone is interested let me know and i will email you all the details etc.
Above is a example of the rear (left) minus brake and the front (right) including optional ADR approved braided lines.
The brackets and the hub rings are zinc plated for corrosion resistance.
An example of fitment on ECKERS race car.
Before 17 inch TE37
After 17 inch TE37
A set under 16 inch Racing Harts
A set under 18 inch Advans
The rear setup under 18 Inch Advans
Edit* Stupid of me to assume people know what these allow the fitment of to your vehicle.
Using a set of R32 GTS-T or Z32 300ZX front alloy brake calipers and a LS400 Lexus front disc for the front
Using the late model 22V GEN3 rear brake calipers and an Mazda RX8 "front" brake disc for the rear.
