1991 Toyota MR-2 GT (Import) Targa Top - Townsville North QLD

Model: SW20 GT Targa Turbo

Year: 1991
Colour: Black
Kms: 91,051
Rego: Current - most likely 12 Months
Location: Townsville, North QLD.

History: Purchased from Corey (JUICED MR2) in 2012
http://www.mr2australia.com/mr2play/tm.aspx?m=31713

Modifications: 201 rear wheel KW

Highly Modified 3SGTE engine under 10,000kms containing the following

• ACL Bearings, big end (Rod) and mains.
• Eagle Forged H-Beam rods
• ARP rod bolts, head bolts
• ACL Forged Pistons 86.5mm
• Flex honed, acid bathed
• 1.6mm Cometic multi-layer Metal Head Gasket
• Kelford 260 duration 10mm intake & 10.5mm Lift exhaust cams.
• Shim under bucket conversion, Shimmed to clearance and New valve springs
• Ferrara 6000 series Stainless Steel 1mm Oversized Intake & Exhaust valves.
• Intake, Exhaust and Piston Chamber ported, knife edged port dividers on both intake & exhaust, throats ported, Valve guides cut flush, 3 angle valve seats. Chamber cleaned up and polished and CC'ed to 9.0:1 Ratio.
• 9:1 Compression ratio.
• New seal kit throughout.
• Late model 5sfe oil pump (high volume gerotor), releif valve shimmed for approximately 70 - 80psi Pressure under Full Load.
• HKS adjustable Cam gears
• Gates Racing Timing Belt less than 10,000 KMS
• brand new highflowed ct20b turbo honed out with t04 internals, steel shaft aluminium compressor wheels
• Aussie 3inch Dump pipe
• 3inch Straight through exhaust.
• Aftermarket Large side mount intercooler
• Walbro GSS 342 High flow Fuel Pump (Rated 255L / Hr)
• Adaptronic 1280 Ecu Tuned
• E Boost Electronic Boost Solenoid
• Removed Air Conditioning
• 1ZZ-FE Coil on Plug Setup (Removed Distributor)
• Modified Sump – extra 1 Litre Oil & Improved Baffling/Windage Tray.
• SARD 800CC side Feed Injectors
• Turbosmart - FPR800 Adjustable Fuel pressure Regulator
• High Flowed 12mm Fuel Rail.
• Exedy Heavy Duty Clutch plate, with Modified pressure plate (extra pressure). Lightened & Balanced flywheel freshly Machined

Interior modifications

• Defi Boost Gauge Blue Light (30PSI)
• Defi Oil Pressure Gauge (up to 140PSI)
• Innovate Motorsports Wideband Air/Fuel Ratio Gauge MTX-L (built into Dump pipe)
• Alpine CDA-9887 Imprint MP3/iPod Stereo
• Alpine PDX-1000.1 D-class AMP
• Pioneer 6.5inch Splits
• 8inch Subwoofer
• Viper Alarm System
• LED upgrade to dash (blue)

Exterior Modifications

• 99 clear blinker upgrade
• Bathurst edition 99 model rear lights
• TOMS Snorkel (passenger)
• Tyres – Toyota Camry Rims with 205/45/R16 Front / 225/45/R16 Rears – Including 5^th Spare
• Removed Rear Wing & Sealed

Extras

• Devils Own Water/Meth Injection Complete Kit DO3,5,7 Nozzles - ready to be installed
• 3 x Solenoids for Pre/Post Turbo injection and external Intercooler Injection
• Solid state Relay to PWM the Pump.
• Wiring installed into Engine bay ready for installation of Water/Meth Injection.
• ST-205 60mm Throttle Body (with stock Intake Adapter)
• GT-30x series Internal waste gate (Same style as XR6 Turbo)



Overall condition: Very Good

Other Info: Purchased as a Bomb, Fixed up and Runs well.

Price: All reasonable Offers Accepted
Contact: tim.s.hinds@gmail.com  or 0400 793 391
