3SGTE built engine/ Apexi AVCr/Tuned length high mount exhaust/GTX3071r. new photo's
After toiling with the 3SGTE for a few years I'm fitting the 3.5 V6 which is better (financially and heat management) suited to the rigors of 300km.
The tuner did a poor tune which broke the turbo core ball bearing sending fragments into the sump with some small grains going through the through the engine. Damage was found by a bearing inspection. The engine has since been removed stripped back to the block, cleaned, inspected, the crank was linished with new bearings fitted to the rods and main journals.
Everything is now back in perfect order ready for assembly. Oil pump was also inspected which is in good order.
ECU is new and a treat to work with and plenty of support out there to get you up and running.
Shipping can be organised through e-Go transport which can have the engine to you for around $200-$350 to just about anywhere or you can pick up from Sydney or I can drop it off as far as Canberra to Bathurst or Newcastle.
Its an excellent opportunity to build a street weapon for a fair price if you when and pieced it together on your own.
Gen 3 block and crank ACL race bearings for crank and rods
Eagle rods, CP pistons and rings
ARP studs :crank and head
New oil pump
Oil sandwich plate for oil cooler
Crank linished, block cleaned and honed
All machine work by Dominator engine reconditioning. Dominator is highly regarded for building engines in Top Fuel Funny car, speedcars, sports sedan, Australian rally championship, Gas motorsports 2JZ drag cars, WTAC.
Head Standard inlet valves, valve seats
BC springs
Titanium valve retainers
Shimless bucket conversion
Power division camshafts. duration 268/lift 10.5 both inlet and exhaust
HKS adjustable cam gears
New Gates timing belt
New timing belt tensionor
New timing belt pulleys
Cometic metal head gasket
Custom thermostat housing and coolant inlet lines
Custom turbo coolant line from thermostat housing
Standard fuel rail, 800cc phoenix power injectors, Earls fittings
Due to the conversion of a electric water pump, you will need a new water pump and plumbing back to the intake manifold.
I have the standard intake manifold as well as the custom unit.
Long engine cost: $4500
Turbo package Custom tuned length high mount turbo manifold to suit Gen .
V band connection from turbo to muffler
GTX3071r with .82 housing and anti- surge inlet housing. The turbo core needs replacement.
Synapse 50mm external wastegate with v band fitting to exit pipe. Some minor work will be required to have this plumbed into the exhaust system
Custom water and oil lines. Stainless lines and fittings for quick easy removal
3" dump pipe, flex fitting under the sump.
All exhaust has been ceramic coated and wrapped in titanium wrap.
The initial cost for this set up was over double the asking price with only a few hours use.
Cost: $1500
ECU and wiring Haletec Sports 1000 tuned to suit the engine but will require refinement before being used for any 'work' .
Coil over plug sequential ignition
MAP is managed by ECU
Has Haltec ECU plugs with coils/injectors/sensors wired in. This will need to be adjusted to suit your application.
ECU was used for less than 30 mins. If it would work with the 2GR I would keep it but it ill not so it has to be sold off.
Cost: $1500
Sold pending payment Boost controllerApexi AVC-r complete with all the wiring, near new Haltec boost controller, 3 bar MAP sensor.
$400
Gen 3 HeadGen 3 head with motorsport valve seats cut to suit OS 1mm valves, bronze guides
$500
1mm OS Inconel exhaust valves
$150
post edited by B24 - 2014/04/05 10:59:01
